Aerocool Hexform Mini Tower Case

Hexform - MINI TOWER CASE
Designed with ventilation in mind, this case delivers superior air flow while allowing for viewing of your front LED fans. This high-performance mini tower case comes equipped with a full tempered glass side panel to showcase the inside of your rig. Supports liquid cooling in the front and rear of the case for maximum cooling efficiency.

- Front panel with air vents delivers superior air flow and ventilation while allowing for viewing of your front LED fans
- Full tempered glass side panel showcases the inside of your rig
- Supports liquid cooling in the front and rear of the case
- Supports air cooling in the front, top, and rear of the case
- Supports CPU cooler up to 159mm
- Supports high-end graphics cards up to 296mm (without front radiator)

Specifications
Model

Hexform

Case Type

Mini Tower

Color

Black

Body Material

SPCC

Front Panel Material

ABS

Steel Thickness

0.5mm

Motherboards

Micro ATX/mini-ITX

Case Dimensions (Internal)

200 x 375 x 306mm (W x H x D)

Case Dimensions (Overall)

207.5 x 377 x 358mm (W x H x D)

3.5" Drive Bays

2 Max. (2 x 3.5"/2.5?)

2.5" Drive Bays

2 Max. (2 x 2.5"/3.5")

Expansion Slots

4

GPU Clearance

Supports GPU up to 296mm (without front radiator)

CPU Cooler Clearance

Supports CPU cooler up to 159mm

Air Cooling

Front: 120mm x 2 or 140mm x 2 (Max)
Top: 120mm x 2 (Max.)
Rear: 120mm x 1 (Max.)

Liquid Cooling

Front: 120/240mm Radiator (Optional)
Rear: 120mm Radiator (Optional) (not compatible with cooler with pump on radiator)

I/O Ports

USB3.0 x 1 | USB2.0 x 2 | HD Audio & Mic.

Internal Cable Management Depth

18.9mm
