TP-Link Omada ER7412-M2 2.5G Multi-WAN VPN Gateway

SECURITY

Access Control

- Source/Destination IP-Based ACL
- Stateful ACL
- IPv4/IPv6 ACL
- National Based ACL

Filtering

- WEB Group Filtering§
- URL Filtering
- Web Security§

ARP Inspection

- Sending GARP Packets§
- ARP Scanning§
- IP-MAC Binding§

Attack Defense

- TCP/UDP/ICMP Flood Defense
- Block TCP Scan (Stealth FIN/Xmas/Null)
- Block Ping from WAN

HARDWARE FEATURES

Standards and Protocols

- IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE802.1q
- TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMP

Interface

- 1× 2.5G RJ45 WAN/LAN Port
- 1× 2.5G RJ45 WAN/LAN Port
- 2× Gigabit SFP WAN/LAN Ports
- 8× Gigabit RJ45 WAN/LAN Ports
- 1× RJ45 Console Port
- 1× USB 3.0 Port (Supports USB storage, and LTE backup with LTE dongle)

Network Media

- 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100O STP (Max 100 m)
- 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100O STP (Max 100 m)
- 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
- 2500BASE-T: UTP category 5e, 6 cable (Max 100 m)

Button

Reset Button

Power Supply

100-240 VAC, 50/60 Hz

Flash

128MB NAND

DRAM

1 GB DDR4

Dimensions ( W x D x H )

11.6×7.1×1.7 in (294×180×44 mm)

Protection

4 kV surge protection

Enclosure

Steel

Mounting

- Desktop
- Rackmountable

Max Power Consumption

18.5W (With USB 3.0 connected)

PERFORMANCE

GRE

- Unencrypted: 1153.0 Mbps
- Encrypted: 559.2 Mbps

WireGuard VPN

771.6 Mbps

Concurrent Session

1,000,000

New Sessions /Second

7,000

NAT (Static IP)

2345.71 Mbps / 2351.22 Mbps

NAT(DHCP)

2353.41 Mbps / 2353.40 Mbps

NAT(PPPoE)

2336.52 Mbps / 2336.08 Mbps

NAT (L2TP)

1937.53 Mbps / 1761.82 Mbps

NAT (PPTP)

1757.54 Mbps / 2011.33 Mbps

IPsec VPN Throughput

- ESP-SHA1-AES256: 1125.60 Mbps
- ESP-SHA256-AES256: 1133.1 Mbps
- ESP-SHA384-AES256: 1126.6 Mbps
- ESP-SHA512-AES256: 1132.8 Mbps

OpenVPN

UDP: 266.2 Mbps

L2TP VPN Throughput

- Unencrypted: 2724.5 Mbps
- Encrypted: 1018.4Mbps

PPTP VPN Throughput

- Unencrypted: 3035 Mbps
- Encrypted: 534.6 Mbps

SSL VPN Throughput

263.1 Mbps

66 Byte Packet forwarding rate

1833 Mbps / 1835 Mbps

1,518 Byte Packet forwarding rate

2461 Mbps / 2461 Mbps

BASIC FUNCTIONS

WAN Connection Type

- Static IP/Dynamic IP
- PPPoE (supports MRU Configuration)
- PPTP
- L2TP
- Mobile Broadband: 4G/3G modem for backup via USB port

MAC Clone

Modify WAN/LAN MAC Address†

DHCP

- DHCP Server
- DHCPv6 PD Server (only in Standalone Mode)
- DHCP Options Customization
- DHCP Address Reservation
- Multi-IP Interfaces
- Multi-Net DHCP

IPv6

StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode

VLAN

802.1Q VLAN

IPTV

IGMP v2/v3 Proxy, Custom Mode, Bridge Mode

ADVANCED FUNCTIONS

Advanced Routing

- Static Routing
- Policy Routing
- RIP (available in Standalone Mode)
- OSPF (available in Standalone Mode)

Bandwidth Control

IP/Port-based Bandwidth Control

Load Balance

- Intelligent Load Balance
- Application Optimized Routing
- Link Backup (Timing, Failover)
- Online Detection

NAT

- One-to-One NAT§
- Multi-Net NAT
- Virtual Server
- Port Triggering§
- NAT-DMZ
- FTP/H.323/SIP/IPSec/PPTP ALG
- UPnP

Session Limit

IP-based Session Limit

VPN

GRE

Only in Standalone Mode

SSL VPN

80 Tunnels

IPsec VPN

- 150 IPSec VPN Tunnels
- LAN-to-LAN, Client-to-LAN
- Main, Aggressive Negotiation Mode
- DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
- IPsec Failover
- IKE v1/v2
- MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
- NAT Traversal (NAT-T)
- Dead Peer Detection (DPD)
- Perfect Forward Secrecy (PFS)

PPTP VPN

- PPTP VPN Server
- PPTP VPN Client (15)**
- 150 Tunnels
- PPTP with MPPE Encryption

L2TP VPN

- L2TP VPN Server
- L2TP VPN Client (15)**
- 150 Tunnels
- L2TP over IPSec

OpenVPN

- OpenVPN Server
- OpenVPN Client (11)**
- 121 OpenVPN Tunnels
- "Certificate + Account" Mode
- Full Mode

AUTHENTICATION

Web Authentication

- No Authentication
- Simple Password*
- Hotspot (Local User/Voucher*/SMS*/Radius*)
- External Radius Server
- External Portal Server*
- LDAP

MANAGEMENT

Omada App

Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.

Centralized Management

- Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller

Cloud Access

Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.

Service Dynamic

DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)

Maintenance

- Web Management Interface
- Remote Management
- Export & Import Configuration
- SNMP v1/v2c/v3*
- Diagnostics (Ping & Traceroute)§
- NTP Synchronize§
- Port Mirroring
- CLI (only in Standalone Mode)
- Syslog Support

Zero-Touch Provisioning

Yes. Requiring the use of Omada Cloud-Based Controller.

Management Features

- Automatic Device Discovery*
- Batch Configuration*
- Batch Firmware Upgrading*
- Intelligent Network Monitoring*
- Abnormal Event Warnings*
- Unified Configuration*
- Reboot Schedule*

OTHERS

Certification

CE, FCC

Package Contents

- ER7412-M2
- Power Cord
- Quick Installation Guide
- Rackmount Kit
- RJ45 Console Cord

System Requirements

- Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11
- MAC OS, NetWare, UNIX or Linux

Environment

- Operating Temperature: 0-45 ? (32-113 ?);
- Storage Temperature: -40-70 ? (-40-158 ?)
- Operating Humidity: 10-90% RH non-condensing
- Storage Humidity: 5-90% non-condensing
