TP-Link SG116 16 Port Gigabit Switch
TP-Link SG116 16 Port Gigabit Switch
5 Year Limited Warranty
Increase Your Network Speed and Save Energy
16-Port Gigabit Desktop Switch
TL-SG116
16 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
Green Ethernet technology saves power consumption
IEEE 802.3× flow control provides reliable data transfer
Steel housing, desktop or wall-mounting design
Support 802.1p/DSCP QoS and IGMP Snooping function
Plug and play, with no configuration needed
Link your devices, Create Convenient Business
The TL-SG116 Desktop Switch provides you an easy way to increase the speed of your network server and backbone connections. Whether you are at home or in the office, the TL-SG116 can always help you deal with your business quickly and easily.
Plug and Play, Easy to Internet
A plug-and-play design makes for easy deployment without the need for a technician. Auto-negotiation on each port senses the link speed of a network device and intelligently adjusts for compatibility and optimal performance.
Gigabit Ports For Faster Speeds
Increase the speed of your network with the TL-SG116 16-port Gigabit desktop switch. Non-blocking, 16 10/100/1000Mbps ports enables instant transferring of large, bandwidth intensive files without interference.
Go Green with Your Ethernet
TP-Link’s latest generation of Unmanaged Switches make use of innovative energy-saving technologies. Power consumption automatically adjusts according to link status and cable length, allowing you to expand your network while minimizing your carbon footprint. Save the planet and lower your energy bills — it’s a win-win!
Specifications
HARDWARE
Standards and Protocols: IEEE 802.3i /802.3u /802.3ab /802.3× /802.1p
Interface: 16 10/100/1000Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX
Fan Quantity: Fanless
Physical Security Lock: Yes
External Power Supply: External Power Adapter (Output: 12VDC / 1.0A)
LED Indicator:
System Power
Link/Act indicators per port built into each RJ-45 port
Dimensions ( W x D x H ): 11.26 × 4.4 × 1.0 in. (286111.725.4 mm)
Max Power Consumption: 10W(220V/50Hz)
Max Heat Dissipation: 34.12BTU/h
PERFORMANCE
Packet Forwarding Rate: 23.8Mpps
MAC Address Table: 8K
Packet Buffer Memory: 4.1Mb
Jumbo Frame: 10KB
SOFTWARE
Advanced Features:
Green Technology
802.3X Flow Control
802.1p/DSCP QoS
IGMP Snooping
Transfer Method: Store and Forward
OTHERS
Certification: CE, FCC ,RoHS
Package Contents:
16-Port 10/100/1000Mbps Desktop Switch
Power Adapter
Installation Guide
Rubber Feet
Environment:
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: –40°C~70°C (-40°F~158°F)
Operating Humidity: 10% ~ 90%, non-condensing
Storage Humidity: 5%~90% non-condensing
